Intel dikabarkan akan meluncurkan motherboard B760 dan CPU Intel Raptor Lake Non K series generasi ke-13 pada tanggal 3 Januari 2023. Tepatnya saat CES 2023, ajang pameran teknologi terbesar yang diadakan di Las Vegas, Amerika Serikat.
Intel Raptor Lake Non K Siap Ramaikan Pasar CPU
Tentu untuk sebagian orang jajaran CPU Intel Raptor Lake non K series bukanlah menjadi misteri. Mengingat beberapa lineup telah bocor. Ini juga beberapa kali dikonfirmasi oleh para OEM partner Intel seperti Microsoft dan Gigabyte.
Related Post
Total setidaknya ada 20 SKU yang kabarnya sedang dipersiapkan Intel di tahun 2023 mendatang. Meliputi CPU 65W, ‘F’ series (tanpa iGPU), dan bagian ‘T’ series dengan TDP 35, mulai dari Intel Core i3 13100, i5 13400, i5 13500, i5 13600, i5 13600, i6 13700 & i9 13900.
Motherboard B670 Siap Menyusul
Seiring dengan dirilisnya Intel Raptor Lake, Intel juga menyiapkan lineup motherboard terbaru yaitu B760. Kabarnya, ini akan menawarkan lebih banyak fitur baru kepada konsumen. Dilengkapi dengan dukungan I/O yang lebih banyak. Chipset motherboard ini akan menyasar pengguna mainstream yang bersaing dengan B650 AMD.
Intel 13th Gen Desktop Features
- Up To 24 Cores & 32 Threads.
- Brand New Raptor Cove CPU Cores.
- Based on 10nm ESF ‘Intel 7’ process node.
- Up To 6.0 GHz clock speeds.
- Up To 41% Multi-Thread Performance Improvement.
- Up To 15% Single-Thread Performance Improvement.
- Double The E-Cores on certain variants.
- Increased Cache for both P-Cores & E-Cores.
- Supported on existing LGA 1700 motherboards.
- New Z790, H770, and B760 motherboards.
- Up To 28 PCIe Lanes (PCH Gen 4 + Gen 3).
- Up To 28 PCIe Lanes (CPU Gen 5 x16 + Gen 4 x12).
- Dual-Channel DDR5-5600 Memory Support.
- 20 PCIe Gen 5 Lanes (x4 reserved for PCH).
- Enhanced Overclocking Features.
- 35-125W PL1 TDP / Up To 253W PL2 TDP.
- AI PCIe M.2 Technology.
- Q4 2022 (K) / Q1 2023 (Non-K).
Intel 13th Gen Lineup
| CPU NAME | SILICON REVISION / QDF | P-CORE COUNT | E-CORE COUNT | TOTAL CORE / THREAD | P-CORE BASE / BOOST (MAX) | P-CORE BOOST (ALL-CORE) | E-CORE BOOST (MAX) | CACHE (TOTAL L2 + L3) | TDP | MSRP |
|---|---|---|---|---|---|---|---|---|---|---|
| Intel Core i9-13900KS | B0 | 8 | 16 | 24 / 32 | TBD / 6.0 GHz | TBD | TBD | 68 MB | 125W (PL1) 253W (PL2) | TBD |
| Intel Core i9-13900K | B0 | 8 | 16 | 24 / 32 | 3.0 / 5.8 GHz | 5.5 GHz (All-Core) | 4.3 GHz | 68 MB | 125W (PL1) 253W (PL2) | $589.9 US |
| Intel Core i9-13900KF | B0 | 8 | 16 | 24 / 32 | 3.0 / 5.8 GHz | 5.5 GHz (All-Core) | 4.3 GHz | 68 MB | 125W (PL1) 253W (PL2) | $564.99 US |
| Intel Core i9-13900 | B0 | 8 | 16 | 24 / 32 | 2.0 / 5.6 GHz | 5.3 GHz (All-Core) | 4.2 GHz | 68 MB | 65W (PL1) ~200W (PL2) | TBA |
| Intel Core i9-13900F | B0 | 8 | 16 | 24 / 32 | 2.0 / 5.6 GHz | 5.3 GHz (All-Core) | 4.2 GHz | 68 MB | 65W (PL1) ~200W (PL2) | TBA |
| Intel Core i9-13900T | B0 | 8 | 16 | 24 / 32 | 1.1 / 5.3 GHz | 4.3 GHz (All-Core) | 3.9 GHz | 68 MB | 35W (PL1) 100W (PL2) | TBA |
| Intel Core i7-13700K | B0 | 8 | 8 | 16 / 24 | 3.4 / 5.4 GHz | 5.3 GHz (All Core) | 4.2 GHz | 54 MB | 125W (PL1) 253W (PL2) | $409.99 US |
| Intel Core i7-13700KF | B0 | 8 | 8 | 16 / 24 | 3.4 / 5.4 GHz | 5.3 GHz (All Core) | 4.2 GHz | 54 MB | 125W (PL1) 253W (PL2) | $384.99 US |
| Intel Core i7-13700 | B0 | 8 | 8 | 16 / 24 | 2.1 / 5.2 GHz | 5.1 GHz (All-Core) | 4.1 GHz | 54 MB | 65W (PL1) TBD (PL2) | TBA |
| Intel Core i7-13700F | B0 | 8 | 8 | 16 / 24 | 2.1 / 5.2 GHz | 5.1 GHz (All-Core) | 4.1 GHz | 54 MB | 65W (PL1) TBD (PL2) | TBA |
| Intel Core i7-13700T | B0 | 8 | 8 | 16 / 24 | 1.4 / 4.9 GHz | 4.2 GHz (All-Core) | 3.6 GHz | 54 MB | 35W (PL1) 100W (PL2) | TBA |
| Intel Core i5-13600K | B0 | 6 | 8 | 14 / 20 | 3.5 / 5.2 GHz | 5.1 GHz (All-Core) | TBD | 44 MB | 125W (PL1) 181W (PL2) | $319.99 US |
| Intel Core i5-13600KF | B0 | 6 | 8 | 14 / 20 | 3.5 / 5.2 GHz | 5.1 GHz (All-Core) | TBD | 44 MB | 125W (PL1) 181W (PL2) | $294.99 US |
| Intel Core i5-13600 | C0 | 6 | 8 | 14 / 20 | 2.7 / TBD GHz | TBD | TBD | 44 MB | 65W (PL1) TBD (PL2) | TBA |
| Intel Core i5-13600T | C0 | 6 | 8 | 14 / 20 | 1.8 / TBD GHz | TBD | TBD | 44 MB | 35W (PL1) 100W (PL2) | TBA |
| Intel Core i5-13500 | C0 | 6 | 8 | 14 / 20 | 2.5 / 4.5 GHz | TBD | TBD | 32 MB | 65W (PL1) TBD (PL2) | TBA |
| Intel Core i5-13500T | C0 | 6 | 8 | 14 / 20 | 1.6 / TBD GHz | TBD | TBD | 32 MB | 35W (PL1) 100W (PL2) | TBA |
| Intel Core i5-13400 | B0 / C0 | 6 | 4 | 10 / 16 | 2.5 / 4.6 GHz | 4.1 GHz (All-Core) | 3.3 GHz | 28 MB | 65W (PL1) TBD (PL2) | TBA |
| Intel Core i5-13400F | B0 / C0 | 6 | 4 | 10 / 16 | 2.5 / 4.6 GHz | 4.1 GHz (All-Core) | 3.3 GHz | 28 MB | 65W (PL1) TBD (PL2) | TBA |
| Intel Core i5-13400T | C0 | 6 | 4 | 10 / 16 | 1.3 / TBD GHz | TBD | TBD | 28 MB | 35W (PL1) 100W (PL2) | TBA |
| Intel Core i3-13100 | H0 | 4 | 0 | 4 / 8 | 3.4 / TBD GHz | TBD | TBD | 12 MB | 60W (PL1) 88W (PL2) | TBA |
| Intel Core i3-13100F | H0 | 4 | 0 | 4 / 8 | 3.4 / TBD GHz | TBD | TBD | 12 MB | 60W (PL1) 88W (PL2) | TBA |
| Intel Core i3-13100T | H0 | 4 | 0 | 4 / 8 | 2.5 / TBD GHz | TBD | TBD | 12 MB | 35W (PL1) 66W (PL2) | TBA |
